1. Thermal Fusion Image ;
2. Light weight,Compact and easy control;
3. Buliting in Laser Range Finder.
4. Builting in Low light CMOS Camera.
5. Builting in GPS
6. Video and picture
7. Zoom:1X, 2X, 3X, 4X
8. E-compass, pitch scale
9. Builting in WIFI for transferring the video.
10. OLED display.
11. Positioning system to locate user and target.
12. Work for long distance in the night.
13. Resolution of the visible light image: 1280×768
14. FOV of the visible light: 12.5°×7°
15. Continuous working time ≥6h；
16. Weight: 1.6kg；
17. Dimension: 185mm×180mm×110mm；
18. IP67 protection
Visible light sensor | Low light CMOS sensor |
Resolution | 1280x768 |
Pitch | 6μm×6μm |
Wave length | 350~1000nm |
Focus length | 35mm |
FOV | 12.5°×7 |
Magnification | 7X |
IR sensor | uncooled |
IR Resolution | 400x300 |
Pitch | 17μm |
Spectrum | 7.5-14 um |
LRF | 2KM |
NETD | <35mk @f/1.0 |
Focus length | 52mm f/1.0 motorized lens |
FOV | 7.8°×6.8° |
Display | 0.5 Inch, OLED, 1024x768 |
Detect Distance | 2KM for human，3KM for Vechihicle |
Image mode | 11 kinds |
Frame | 50HZ |
Diopter adjustment | 0-3° |
IR Magnificaiton | 8X |
Zoom | 1X,2X,3X,4X |
Max magnification | 32X |
Storage | Built-in 64G |
Capture | Yes |
WIFI | Yes |
Video | Yes |
Battery | 4 pcs of 18650 battery |
Working hours | ≥8 hours |
Storage temperature | -40℃ to+60℃ |
Waterproof | IP67 |
Weight | <1.6kgs（without battery ） |
Dimension | 185mmx180mmx110mm |
Focus | Auto/motorized |
GPS | yes |
GPS accuracy | ≤2m |
E-compass | Yes |
