M500X Thermal riflescope

Infrared

Detector type

 uncooled

Resolution ratio

640×512

Pixel size

12μm

Focus length

25mm

35mm

54mm

75mm

Field angle

17.5°× 14.0°

12.5°× 10.0°

8.1°×6.5°

5.9°×4.7°

Work band

8~14μm

NETD

≤ 40mk@25℃ ,@F/ 1.0

Frame rate

≤50Hz

Focusing mode

Manual

Detection range

Character

1.7mx0.5mx0.3m

2361m

3306m

5100m

7083m

Vehicle

4.5mx2.0mx1.5m

6250m

8750m

13500m

18750m

Character

1.7mx0.5mx0.3m

590m

826m

1275m

1771m

Vehicle

4.5mx2.0mx1.5m

1563m

2188m

3375m

4688m

Display

Display screen type

OLED

Resolution ratio

1440× 1080

Display size

0.39inches

Electronic zoom

1×/2×/4×/8×

Diopter regulation

±5SD

Hot  track

Supported

Picture in picture

Supported

Language

Simplified Chinese, Traditional Chinese, English, Russian and German

Storage

Capacity

Built-in 16G EMMC(The system takes up some space and it is 13.8G actually)

Photographing

Supported

recording

Supported

Image/video format

JPG/MP4

Interface

USB interface

Charging/export image and video

Power

Detachable recharge- able lithium battery

1400mAh×2(battery model 18350)

General technical index

Overall power consumption

≤1.8W

Time of endurance

≥5 hours

Work temperature

-20℃ ~ +60℃

Storage temperature

-30℃ ~ +70℃

Impact

≤1000G

Protection grade

IP66

Size/weight

Product size

201x66x73mm

Product weight

650g
