Specifications :
Model | 111 | |
Magnification | 8x | |
Objective (mm) | 30 | |
Ocular lens (mm) | 21.5 | |
Field of view | View angle | 7.8° |
M/1000M | 136 | |
FT/1000YDS | 408 | |
Eyes relief (mm) | 16 | |
Diopter adjustment | Right diopter ring : ±4° | |
Focus | Center focus | |
Exit pupil (mm) | 3.75 | |
Prism system | Porro | |
Eyecups | Folded down | |
Fog and waterproof | Yes | |
Net weight(g) | 690g | |
Size L xW x H (mm) | 175x 60 x128 | |
Standard | MiL-STD-810 | |
Interpupillary distance | 52－73 ㎜ | |
Drawing scale in the right telescope | Yes | |
Resolution | <50 ' | |
Light transmission. Laser protected | yes | |
Convergence | <60 ' | |
Divergence | <30' | |
Elevation | ± 15 ' | |
Image inclination | <± 1 ° | |
Distance (visibility 20km) | ||
Identification of target (2.3X2.3m) | 1000m | |
Identification of huan(1.7m tall) | 150m | |
Material | ||
Housing material | Aluminium alloy | |
Armor material | NBR+PVC | |
Optical material | Optical glass | |
Coating | ||
Lens coatinig | 420-680nm,R＜0.5%(AVG), 420-680nm, R＜1.0% (ABS),blue 550nm（MGF2) | |
Prism coating | Blue 550nm（MGF2) | |
Packaging | ||
Bag | Yes | |
strap | yes | |
